Ebara BEST ONE – VOX
AISI 304 stainless steel submersible pump with mechanical seal made of Ceramic/Carbon/NBR and oversized oil chamber. Possibility of fixed or mobile installation and suitable for domestic applications and large industrial drainage installations.
Features
Description
Reviews (0)
AISI 304 stainless steel submersible pump with mechanical seal in Ceramic/Carbon/NBR and oversized oil chamber that increase the life and reliability.
BEST ONE has a semi-open impeller, while BEST ONE VOX is equipped with vortex type impeller, to ensure a greater free passage and reduce the possibility of clogging.
The electric pumps offer great versatility of installation (fixed or mobile) due to the possibility of choosing between the vertical magnetic float switch (of reduced size) or the float switch.
These solutions also allow you to choose the best pump insertion option according to the space available.
For further technical information see the Databook
• Emptying of basements, garages, cellars or rooms subject to flooding
• Emptying of tanks and reservoirs
• Supply of garden fountains
Technical data
|
Flow rate
|
from 1.2 to 10.2 m³/h
|
|
Total head
|
From 1.8 to 8.3 m for BEST
ONE and From 1.5 to 6 m for BEST ONE VOX |
|
Max. temperature of the liquid
|
+50°C
|
|
Poles
|
2
|
|
Max. solids passage
|
10 mm
20 mm for VOX version (Vortex) |
|
Insulation class
|
F
|
|
Protection degree
|
IP68
|
|
Voltage
|
Single-phase 1~230V ±10%
Three-phase 3~400 ±10% |
|
Max. immersion
|
5 m with 10 m cable
2 m with 5 m cable |
Materials
|
Pump body
|
Stainless steel AISI 304 (EN 1.4301)
|
|
Impeller
|
Stainless steel AISI 304 (EN 1.4301)
|
|
Shaft
|
Stainless steel AISI 303 (EN 1.4305) (part in contact with liquid)
|
|
Mechanical seal
|
Ceramic/Carbon/NBR (mechanical seal)
NBR (lip seal) |
