KAMA DIESEL ENGINE KM170F

Tools & Machinery Division Electrical Division
  Delivery & Return
1200+ products

,

  Size Guide
1200+ products

,

Categories:,
Description
Reviews (0)

Specifications:

Engine type Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Bore*stroke[mm(in)] 70×55(2.76×2.17)
Dispiacement[ml(cu.in)] 211(12.88)
Engine speed(rpm) 3000/3600
Compression ratio 20:1
Rated output power[kW(HP)/rpm] 2.5(3.4)/3000,2.8(3.8)/3600
Rotation direction (view from flywheel) Clockwise
Fuel 0#or-10#light diesel oil
Fuel tank volume[L(gal.)] 2.5(0.55)
Fuel consumption rate[g(ml)/kW.h] 3000rpm:280(333),3600rpm:288(342)
Lubrication oil volume[L(gal.)] 0.8(0.180)
Power-Take-Off Crankshaft or Camshaft
Starting system Recoil
Overall dimension(L*W*H)[mm(in)] 332x348x416(13.07×13.70×16.38)
Dry weight[kg(ibs.)] 26(57.2)
Lube brand SAE10W30(above CC grade )
