- 6 position power settings.
- Deliver 1,000 ft-lb of Max torque with 5,500 rpm free speed.
- Available in 6″ extended anvil for model IW-6430.
- Suitable for tire or engine work on truck, bus or farm machinery.
Specification
|
Impact Mechanism
|
New Twin Hammer |
|---|---|
|
Free Speed
|
5,500 RPM |
|
Max. Torque
|
1,100 ft/lb (1,492 Nm) |
|
Avg. Air Cons.
|
9.5 CFM (269 l/min) |
|
Working Pressure
|
90 PSI (6.2 Bar) |
|
Net Weight
|
5.6 Kgs (12.4 lbs) |
|
Overall Length
|
220 mm (8.7″) |
|
Air Inlet
|
3/8″ |
|
Air Hose I.D.
|
1/2″ |
|
Air Exhaust
|
Rear |
|
Sound Noise
|
96 dB(A) |
|
Vibration Level
|
10.22 m/s² |
