MASTERMIG 270/2 230-400V
code 821065
• MIG-MAG/BRAZING welding machine.
• Designed for continuous and spot welding with electronic regulationof spot welding time.
• Thanks to optional kit this model allows also sheet tempering.
• Flexibility of use with a wide range of materials such as steel, stainless steel, high strength steels and aluminium.
• Complete with MIG-MAG welding accessories.
IM2290
CE MARKING
3 PH 230V-400V
EAC CERTIFICATION
COIL 15 kg
TÜV CERTIFICATION| CODE | 821065 |
|---|---|
| THREE PHASE MAINS VOLTAGE | 230 / 400 V |
| MAINS FREQUENCY | 50 / 60 Hz |
| CURRENT RANGE | 28 – 270 A |
| MAX CURRENT | 240 @ 30 % A |
| DC CURRENT | 160 A |
| MAX NO LOAD VOLTAGE | 37,3 V |
| MAX ABSORBED POWER | 9 kW |
| ABSORBED POWER AT 60% | 5,5 kW |
| POWER FACTOR | 0,9 |
| ADJUSTMENT POSITIONS | 10 |
| STEEL WELDING WIRE DIAMETER | 0,6 – 1,2 mm |
| INOX WELDING WIRE DIAMETER | 0,8 – 1 mm |
| ALUMINIUM WELDING WIRE DIAM. | 0,8 – 1 mm |
| BRAZING WIRE DIAM. | 0,8 – 1 mm |
| PROTECTION DEGREE | IP22 |
| DIMENSIONS | 87 x 45,3 x 80 cm |
| WEIGHT | 66 kg |
| EAN CODE | 800489764040 2 |
| PIECES/PALLET | 3 pz/pallet |
