Specifications
| Model | CV150 |
| Machine type | Modular – main machine + separate ice bin |
| Ice type | Clear cube ice (small cube) |
| Machine dimensions (W × D × H) | 565 × 830 × 1540 mm (assembled unit) |
| Production | |
| Daily ice output (21 °C air / 16 °C water) | 158 kg / 24 h |
| Storage bin capacity | 120 kg |
| Cooling & Refrigeration | |
| Condenser unit | Air / Water (dual option) |
| Refrigerant | R290 |
| Electrical | |
| Rated voltage / frequency | 220 V / 50 Hz |
| Power consumption | 800 W |
| Physical – Net Weight | |
| Net weight – main machine | 46 kg |
| Net weight – ice bin | 31.4 kg |
| Physical – Gross Weight | |
| Gross weight – main machine | 52 kg |
| Gross weight – ice bin | 37.4 kg |
| Carton Dimensions (L × W × H) | |
| Carton – main machine | 710 × 650 × 620 mm |
| Carton – ice bin | 820 × 600 × 880 mm |
| Standard Working Conditions | |
| Input water temperature | 16 °C |
| Ambient temperature | 21 °C |
| Condensing temperature | 40 °C |
| Compliance & Warranty | |
| Control system | Microcomputer (PLC intelligent control) |
| Certification | ISO 9001, CE |
| Warranty | 1 year |
