Specifications
| Cylinder Gas | Model | Maximum Inlet Pressure | CGA Inlet | CGA Outlet | Capacity |
|---|---|---|---|---|---|
| – | FM370 | 25 psig | 9/16″-18 RH F | 5/8″-18 RH F | |
| – | FM200 | 30 psig | 1/4″ NPT M | 5/8″-18 RH M | 30-100 cfh |
| Air | FM150 | – | – | 10-60 cfh | |
| Nitrogen | FM150 | – | – | 10-30 cfh | |
| Argon | FM370 | – | – | 5-50 cfh | |
| Helium | FM137 | – | – | 40-200 cfh | |
| CO₂ | FM372 | – | – | 5-40 cfh | |
| Nitrogen/Air | FM150 | – | – | 10-60 cfh | |
| – | FM 371 | 25 psig | 5/8″-18 RH(M) | 5/8″-18 RH(F) | |
| – | FM155 | 25 psig | 5/8″ NPT M | 5/8″-18 RH F | |
| – | FM 372 | 25 psig | 1/4″ NPT(M) | 5/8″-18 RH(F) | |
| – | FM370 | 25 psig | 9/16″-18 RH(F) | 5/8″-18 RH(F) | 5-40 cfh |
| – | FM 200 | 80 psig | 1/4″ NPT(M) | 5/8″-18 RH(F) | |
| – | FM157 | 25 psig | 1/4″ NPT M | 5/8″-18 RH F | |
| – | FM145 | 25 psig | 5/8″ RH M | 5/8″-18 RH F | |
| Argon | FM 371 | – | – | 5-50 cfh | |
| Argon | FM 155 | – | – | 4-18 cfh | |
| Helium | FM370 | – | – | 20-150 cfh | |
| Helium | FM147 | – | – | 40-200 cfh | |
| CO₂ | FM 371 | – | – | 5-40 cfh | |
| Argon | FM372 | – | – | 5-50 cfh | |
| Argon | FM157 | – | – | 15-65 cfh | |
| Argon | FM147 | – | – | 15-70 cfh | |
| Argon | FM137 | – | – | 15-65 cfh | |
| Argon | FM135 | – | – | 4-18 cfh | |
| Helium | FM155 | – | – | 10-50 cfh | |
| Helium | FM145 | – | – | 10-50 cfh | |
| Helium | FM135 | – | – | 10-50 cfh | |
| Helium | FM372 | – | – | 20-150 cfh | |
| CO₂ | FM200 | – | – | 30-100 cfh | |
| Nitrogen/Air | FM150 | – | – | 10-60 cfh |
Ordering
| Description | Product Number |
|---|---|
| Victor Professional Flow Meter FM 372, Three Gas Calibration, 40/50/150 SCFH, CO2/Ar/He, 1/4 NPT Inlet, 5/8-18 RH(F) Outlet | 1000-0182 |
| Victor Professional Flow Meter FM 135, Two Gas Calibration, 18/50 SCFH, Ar/He, 9/16-18 RH (F) Inlet, 5/8-18 RH (F) Outlet | 1000-0255 |
| Victor Professional Flow Meter FM 155, Two Gas Calibration, 18/50 SCFH, Ar/He, 1/4 NPT Inlet, 5/8-18 RH(F) Outlet | 1000-0257 |
| Victor Professional Flow Meter FM 370, Three Gas Calibration, 40/50/150 SCFH, CO2/Ar/He, 9/16-18 RH (F) Inlet, 5/8-18 RH (F) Outlet | 1000-0258 |
| Victor Professional Flow Meter FM 371, Three Gas Calibration, 40/50/150 SCFH, CO2/Ar/He, 5/8-18 RH (M) Inlet, 5/8-18 RH (F) Outlet | 1000-0259 |
| Victor Professional Flow Meter FM 137, Two Gas Calibration, 65/200 SCFH, Ar/He, 9/16-18 RH (F) Inlet, 5/8-18 RH (F) Outlet | 1000-0261 |
| Victor Professional Flow Meter FM 147, Two Gas Calibration, 70/200 SCFH, Ar/He, 5/8-18 RH (M) Inlet, 5/8-18 RH (F) Outlet | 1000-0262 |
| Victor Professional Flow Meter FM 157, Two Gas Calibration, 65/200 SCFH, Ar/He, 1/4 NPT (M) Inlet, 5/8-18 RH(F) Outlet | 1000-0263 |
| Victor Professional Flow Meter FM 200, Single Gas Calibration, 100 SCFH, CO2, 1/4 NPT (M) Inlet, 5/8-18 RH(F) Outlet | 1000-0264 |
| Victor Professional Flow Meter FM 150, Two Gas Calibration, 60/60 SCFH, Air/N2, 1/4 NPT (M) Inlet, 5/8-18 RH(F) Outlet | 1000-0268 |
