| Model | LCB-1B |
|---|---|
| Max Airflow | 9500 M³/H |
| Effective Area | 30-55 M² |
| Rated Voltage/Frequency | 220-240 V, 50/60 Hz |
| Power | 340 W |
| Weight | 32 KG |
| Water Capacity | 60 L |
| Water Consumption | 4-6 L/H |
| Noise | 53/58/63 |
| Dimension | 890*490*1440 MM |
Specifications
Frequency: 50 Hz
Max. Output: 8 kW
Rated Output: 7.5 kW
Rated AC Voltage: 220 V
Power Factor: 1
DC Output: 12V / 8.3A
Phase: Single Phase
Starting System: Electric
Noise Level (at 7 m): 75–78 dB
Fuel Tank Capacity: 30 L
Continuous Working Time: 12 Hours
Engine Type: Single-Cylinder, Vertical, 4-Stroke Air-Cooled Diesel Engine
Bore × Stroke: 98 × 84 mm
Fuel: 0# or -10# Light Diesel Oil
Lubrication Oil Volume: 1.65 L
Battery Capacity: 12V 36Ah
Voltmeter: Yes
AC Output Socket: 2
AC Circuit Breaker: Yes
Oil Warning Light: Yes
Oil Alert: Yes
Wheels: Yes
Dimensions (L × W × H): 106 × 72 × 86 cm
Gross Weight: 220 kg
