- Rice field irrigation
- Irrigation with sprinkler systems
- Gardening / orchard cultivation
- Pump water from well
- Filling water reservoirs
- Filling or draining water from ponds
- Filling or draining water from fish farms
- Washing livestock, barns or farm equipment
- Pumping water with solid particles up to 3 mm
Performance Curve:
Documentation:
* This link leads to the parts list of the model SEV-50X-BAE. If the complete designation of your pump model differs from this, please ask us for the correct parts list via our contact form.
Technical information:
| MODEL | SEV-50X |
| Connection | 50 mm (2″) |
| Connection type | Outer pipe thread |
| Total head | 27 m |
| Capacity | 620 L/min |
| Suction height | 8 m (26 ft) |
| Grain sizeGrain size | Max. 3 mm |
| Motor type | 4-stroke gasoline engine, air-cooled |
| Motor | Koshin K180 |
| Displacement | 179 cm3 |
| Nominal power | 3.1 kW (4.2 hp) / 3600 rmp |
| Max. Power | 3.5 kW (4.8 hp) / 3600 rpm |
| Fuel | Gasoline, unleaded |
| Tank capacity | 3.6 l |
| Cont. Operating time | Approx. 2.6 hrs. |
| Start method | Cable starter |
| Scope of delivery | 1 filter, 2 hose couplings, 3 hose clamps, 1 motor tool |
| Weight, net | 25.2 kg |
| Weight, gross | 27.2 kg |
| Dimensions LxWxH (cm) | 50.4 × 40.5 × 41.1 |
Power
(varies depending on hose material)
Maximum feed distance
with horizontal installation:189 m
Max. Delivery head:32M Max. Intake height:8M
Each motor pump is equipped with accessories
Hose couplings х 2
Filter х 1
Hose clamps х 3
Motor tool x 1
