PRODUCT FUNCTIONS
- Excellent arcing and stable arc
- Stably start arcing at low current 10A
- No Arc Blow
PRODUCT ACCESSORIES
- TIG Torch 4mtr length
- Holder & Cable Clamp 3mtr length
PRODUCT DISCRIPTION
- DC manual welding, AC/DC/pulse ITG function, one machine for multiple uses
- The multifunctional welding machine has both 2T/4T functions for efficient welding
- The pulse frequency, peak value, base value, and other parameters can be adjusted to meet different welding
- The gas delay and pulse width cleaning can be adjusted to ensure that the weld bead does not turn black and the welding is more secure
- The output waveform for communication includes square wave, sine wave, and triangular wave modes, and supports combined output modes
- Comprehensive protection against overcurrent and overheating
- Strong ability to withstand power grid fluctuations and work normally even with unstable voltage
- Weldable carbon steel, ordinary low-alloy steel, stainless steel, aluminum and aluminum alloy products
Specifications
| Model | ACDC500 |
| Voltage (V): | 380V ±15% (3 Phase) |
| Frequency (Hz): | 50–60 |
| Input Power (KVA): | 19 |
| No-Load Voltage (V): | 56 |
| TIG Current Range (A): | 10–500 |
| MMA Current Range (A): | 20–400 |
| Duty Cycle: | 60% |
| MMA Welding Rod (mm): | 1.6–5.0 |
| Power Factor: | 0.73 |
| Efficiency (%): | 85 |
| Insulation Grade: | F |
| Protection Grade: | IP21S |
| Weight (Kg): | 50 |
| Dimensions (L×W×H mm): | 670 × 440 × 790 |
| Carton CBM (m³): | 0.233 |
| Pre Gas: | ✔ |
| Post Gas: | ✔ |
| Current Up Slope: | ✔ |
| Current Down Slope: | ✔ |
| Pulse Frequency Adjustable: | ✔ |
| Clean Width Adjustable: | ✔ |
| Pulse Width Adjustable: | ✔ |
| 2T/4T: | ✔ |
| Automatic Voltage Compensation: | ✔ |
| Over Heat Protection: | ✔ |
| Under Voltage Adjustable: | ✔ |
| TIG Torch: | WP–12–4M |
